The PD10 Padel Court is designed for extreme climate regions, and is especially suitable for regions such as the Middle East or Southeast Asia. Certified by both CE and GB standards, this product features a robust design incorporating laser-cut galvanized steel and 12mm shatterproof glass. Many ordinary sports courts are exposed to high temperatures or humidity, leading to issues such as rust, glass aging, and turf damage. These problems result in high maintenance costs. In contrast, this product offers a service life of over 12 years even under these extreme conditions, thereby significantly reducing both maintenance and energy expenses.
In this guide, you’ll learn what a padel court is, the specifications of the PD10, and why it does better than standard courts in heat, humidity, and long-term ROI .
What Is a Padel Court?
A padel court is an enclosed, smaller version of a tennis court, typically played in doubles. Standard padel court dimensions are 20m long × 10m wide, with walls made of glass or solid materials.
If you need a padel court that can handle extreme climates like 45°C heat or high humidity, the PD10 is built for that. But it also works perfectly for everyday settings like sports centers, communities, or schools. It’s factory direct, fully customizable, and ready for your project.
Padel Court Size & Technical Specifications
| Product Model | PD10 |
| Court Size | 20 meters long and 10 meters wide |
| Surface Course | Artificial Short Grass: 12mm, in compliance with GB/T 20394-2013 “Artificial Grass for Sports” premium product; |
| Sand Filling: 120 mesh quartz sand, with a sand filling quantity of 5kg/square meter, and ensuring uniform sand filling; | |
| Tempering Glass | Specially made explosion-proof tempered glass, size 2995mm * 1995mm, thickness 12mm |
| Column and Fence | high-quality steel pipe:Corner column: 100mm * 100mm * 3mm； |
| Crossbeam: 50mm * 100mm * 3mm, other columns: 50mm * 100mm * 3mm; | |
| Mesh Frame: 30mm * 50mm * 2mm, welded with 3mm thick steel plate； | |
| End and Side Fence: 4m, side middle fence: 3m； | |
| Mesh Diameter: 4mm, mesh size: 50mm * 50mm; | |
| Lighting | 8 sets of LED lighting fixtures, each with a power of 200W; |
| The lamp post is embedded inside the fence, with a height of 6000mm; Illumination reaches 300Lux； | |
| Customized | Support all customization |
Padel Court Construction: What Makes PD10 Different?
PD10 Lasts Longer: Material, Process & Durability
Material. Ordinary steel pipes exhibit poor corrosion resistance and rust from the inside out. This corrosion often goes unnoticed until structural displacement eventually occurs. The PD10, however, is different. We galvanize every surface and use SPHC grade steel, which is more corrosion resistant than the steel used by most manufacturers, greatly increasing its service life.
Manufacturing process. All components of the PD10 are made using laser cutting and bending processes, which means that each part fits perfectly without any weak points. By combining robotic and manual welding methods, the entire frame was welded, instead of the spot welding that would crack after a few years. Furthermore, its coating process encompasses shot blasting, electrostatic powder coating, and automated curing production lines.
Durability and lifespan. We implement strict quality control on glass, lighting, and steel structures to ensure the quality of every product. This product uses export-grade packaging to prevent damage during transportation, ensuring its integrity even after long-distance sea voyages. Our padel court boasts a service life of 12 years or more.
Certified for Global Markets
The PD10 adopts a prefabricated modular design, which is manufactured in the factory and assembled on site, thus avoiding common construction problems. This product holds three key certifications: a safety certification for outdoor fitness equipment compliant with the GB 19272-2011 standard; a certification for high-quality artificial turf compliant with the GB/T 20394-2013 standard; and a safety certification for tempered glass compliant with the CE EN 12150-2:2004 standard. With these certifications, you can install this product in the Middle East, Southeast Asia, Europe, and the Americas, fully complying with local regulations.
Built for Extreme Climates
The PD10 is designed for harsh environments that ordinary padel court cannot handle. In high-temperature regions—such as Saudi Arabia, the UAE, Qatar, Kuwait, and parts of Africa, where temperatures frequently exceed 45°C, the PD10 stands up to the extreme heat thanks to its UV-resistant artificial turf, hot-dip galvanized steel posts, and UV-protective coatings applied to all exposed surfaces. In humid and rainy regions such as the Philippines, Indonesia, Thailand, and Malaysia, the PD10 effectively combats moisture erosion thanks to its efficient drainage system, anti-slip artificial turf, and comprehensive anti-corrosion treatment including galvanizing and surface coating.
Application Scenarios：
Typical customer distribution (based on actual sales):
| Customer type | Percentage |
| Padel clubs & investors | 50% |
| Real estate developers / hotels / resorts / | 30% |
| Schools & government projects | 20% |
Case Study: PD10 in Saudi Arabia
As a leading padel court manufacturer and supplier in China, we successfully completed a high performance padel court project in Saudi Arabia, where summer temperatures often exceed 45°C. The client needed a durable, low maintenance solution for a new padel club. To meet this challenge, we supplied our PD10 padel tennis court, which features UV resistant artificial grass, a hot dip galvanized steel structure, and an advanced anti corrosion coating.
Padel Court Construction Cost & Customer Benefits
When calculating padel court construction cost, buyers often focus only on upfront price. The PD10 offers lower total cost of ownership.
Quantified customer benefits:
| Metric | Improvement |
| Annual energy consumption | ↓ 23% |
| Annual maintenance cost | ↓ 15% |
| Court lifespan | Extended by 4 years or more |
FAQ
Q: Do you provide installation support?
A: Yes, we offer manuals, videos, and engineering guidance; on-site supervision is optional.
Q: How long is production and shipping?
A: Production is 20–30 days after deposit. Shipping depends on destination port.
Q: Why choose your company as a padel court supplier?
A: We are a factory-direct manufacturer with global project experience, stable supply, and reliable after-sales support.
Conclusion
A padel court represents a long-term investment. While initial purchase costs are important, what truly matters is how the court performs after one, five, or even ten years of use in your local climate.
If you are interested in our products, please feel free to let us know your site conditions, local climate, and any customization needs. Our specialists will be happy to provide you with specific advice.
